ProductsMechanized Welding System




Track-Carriage Seamers


Perfect Welding Auxiliary equipment-Gantry Frame Beam Use with other auxiliary equipment to do longitudinal and circumferential seam welding

Applications

Water Tank
Stainless Steel Pipe
  • The system is used for welding circumferential seam and longitudinal seam of work-piece; it is advantageous in small floorprint and easy work-piece loading. It always works with rotation table, work piece support, fixture or rollers. It can fit out with TIG, MIG/MAG or PAW welding process, suitable for welding stainless steel pipes, vessels, and so on.
  • >> Suitable for longitudinal seam welding of big diameter pipe or barrels
  • >> Weld circumferential seams in cooperation with rollers and headstock
  • >> Suitable for carbon steel, stainless steel
  • >> Suitable for TIG, MIG/MAG, PAW welding process
  • >> Small floorprint, easy work-piece loading.

  • Item

    HLM5000

    HLM6500

    Maximum welding diameter (mm)

    5000

    6500

    Column speed of up and down (mm/min)

    560

    560

    Trolley speed (mm/min)

    80～800

    80～800

    Dimension (LxWxH mm)

    5800*1800*2500

    7600*1800*2500

    Weight (Ton)

    1.6

    1.9
