2 Axes Positioner | Huaheng

Huaheng

Programmable robot external axes, matching up with robot to achieve best welding effect

>> Axes positioner has enough strength and stiffness to ensure normal welding and operator’s safety, with liable self-lock function
>> Grounding electrode connection to the small rotary.

	HDK01	HDK10	HDK25
Tip-over
Max. Speed		30°/sec	16°/sec
Rotation Angle	0～90°	115°	115°
Max Output Torque		4400 Nm	21000 Nm
Repeatability			± 2.0 arc min
Rotary
Max. Speed	144°/sec	65°/sec	42°/sec
Max Output Torque	850 Nm	2200 Nm	4300 Nm
Rotation Angle	±185°	±185°	±185°
Repeatability	±1.0 arc min	± 1.5 arc min	± 1.5 arc min
Payload	100 kg	1000 kg	2500kg
